TF75BK00-OR-432
Size: AS568-432 O-Ring
TF75BK00
Teflon® FEP Encapsulated FKM
75
Shore A
FKM Core
Encapsulated
Color: Black
Detailed Description
TF75BK00-OR-432 is a Black, 75 Shore A, Teflon® FEP Encapsulated FKM O-Ring, a FKM Core product. TF75BK00 is manufactured with the following features & specifications: Encapsulated. TF75BK00-OR-432 is AS568 size -432 O-Ring also referred to as 6.99mm (Cross Sectional Diameter (CS)) x 135.89mm (Inside Diameter (ID)).
| Technical Specification | Value |
|---|---|
| Compound Number | TF75BK00 |
| Material | Teflon® FEP Encapsulated FKM |
| Subtype | FKM Core |
| Color | Black |
| Durometer | 75 Shore A |
| High Temperature | 205 °C / 401 °F |
| Low Temperature | -26 °C / -15 °F |
| Geometry Specifications | |
| Cross Sectional Geometry | O-Ring |
| Size Standard | AS568 |
| Size | -432 |
| Cross Section (CS) | 6.99 mm / 0.275 in |
| Inside Diameter (ID) | 135.89 mm / 5.350 in |
| Other Specifications | |
Encapsulated | |
