Image shown is representative and may differ from the actual product in size, proportions, and color shade
0.139 in
(3.53 mm)
5.234 in
(132.94 mm)
FKM Parker HF355-65 X-Ring, Size: -252
Material: FKM Parker HF355-65 X-Ring
Size: AS568 -252 X-Ring
Part Number: HF355-65-XR-252
Color: Translucent (Clear)
Detailed Description
HF355-65-XR-252 is a Translucent (Clear), 65 Shore A, FKM (Viton®) X-Ring made from Parker Seal® (Parker). It is a 65 durometer FKM (Viton®). Parker Seal® (Parker) HF355-65 is manufactured with the following features & specifications: HiFluor, USP Class VI. HF355-65-XR-252 is AS568 size -252 X-Ring also referred to as 3.53mm (Cross Sectional Diameter (CS)) x 132.94mm (Inside Diameter (ID)). Material: 65 Durometer FKM Parker HF355-65 X-Ring Size: AS568 -252, 3.53mm CS X 132.94mm ID (0.139" CS X 5.234" ID)
| Technical Specification | Value |
|---|---|
| Compound Number | HF355-65 |
| Brand | Parker Seal® (Parker) |
| Material | FKM (Viton®) |
| Color | Translucent (Clear) |
| Durometer | 65 Shore A Hardness |
| High Temperature | 204 °C / 399 °F |
| Low Temperature | -26 °C / -15 °F |
| Geometry Specifications | |
| Cross Sectional Geometry | X-Ring |
| Size Standard | AS568 |
| Size | -252 |
| Cross Section (CS) | 3.53 mm / 0.139 in |
| Inside Diameter (ID) | 132.94 mm / 5.234 in |
| Other Specifications | |
HiFluor | |
USP Class VI | |
